Description

Olympus DP-2000 Delta Premium Alloy XRF Analyzer

Olympus DP-2000 Handheld X-ray fluorescence analyzers provide decisive results to multiple industries with varied applications. Elements such as lead, mercury, arsenic, copper, gold, silver, platinum, and more are detectable in concentrations of parts per million (PPM) up to 100%, with little or no sample preparation requirements.

The New Generation DELTA Handheld XRF analyzers are ergonomically advanced with a forward looking design incorporating the latest in electronics, components, and software technology. The DELTA X-act Count Technology can provide even better sensitivity and precision in faster time for more materials than before.

Olympus DP-2000 is a handheld X-ray fluorescence analyzer designed for various industries and applications. It offers nondestructive testing with the ability to detect elements like lead, mercury, arsenic, copper, gold, silver, platinum, and more in concentrations up to 100% parts per million (PPM). With its advanced features and cutting-edge technology, this analyzer provides precise results quickly and efficiently.

This model contains the following modes: Soils, Alloy Plus, Mining, Mining Plus, Geochem. All modes were installed on this unit to be showcased to potential buyers (Miners, Environmental testers, and Jewelers)

The XRF displayed fairly accurate element analysis of the ores compared to the results from an analysis laboratory company. This unit can also analyze various precious metal elements such as gold, silver, and platinum. This model can analyze many different types of elements such as but not limited to Mg, Al, Si, P, S, K, Ca, Ti, Pb, Zn, etc.

Combining a large area, high performance Silicon Drift Detector (SDD) and a 4W optimized x-ray tube, the DELTA Premium is the ideal solution for ultra quick, analytically demanding applications with superior detection limits. The DELTA Premium with the rhodium (Rh) tube configuration is ideal for superior detection limits for light elements magnesium (Mg), aluminum (Al) and silicon (Si) as well as excellent detection limits for Mg through antimony (Sb). The DELTA Premium model for Alloys & Metals Analysis is referred to as DP-2000.

Alloy Positive Material Identification/QA/QC

The DELTA analytical and positive material inspection (PMI) analyzer is vital for quality control and assurance in the metal manufacturing and fabrication industries. It is used for compositional analysis and alloy grade identifi cation, from critical components to raw materials to welds.

Jewelry / Precious Metals Identification

The DELTA provides fast, accurate alloy chemistry and karat classifi cation with one nondestructive, non intrusive test. Whether importing precious metals, selling or producing jewelry, or processing scrap metal, the DELTA is the ideal choice.

Regulatory and Safety Screening

The DELTA screens for pollutants and poisons such as lead, cadmium, chromium, mercury, arsenic and other toxic elements. It is used to help ensure safety and to help comply with global regulatory programs directed by EPA, RoHS/WEEE EU Member States? Enforcement Bodies, CPSC, FDA, Border Patrol and more.

Geochemestry and Mining Exploration

The DELTA provides immediate results to help determine the next course of action throughout the entire mining process ? exploration, grade/process control, and environmental sustainability. On-site detection of metals, minerals & contaminants and GPS-GIS XRF for instant metal mapping ensures time and cost savings.

The DELTA Premium is the ideal handheld XRF analyzer for ultra quick, analytically demanding applications such as trace levels and light elements in low alloy steel, soil, mining, and metallurgical samples.

The DELTA Premium large area SDD and advanced 4W application optimized X-ray tube provide tremendous speed and superior light element analysis in air.

Features Olympus DP-2000

• Powerful 4W X-ray tube, 200 µA current (max), optimized beam settings
• Tight geometry for exceptional LODs and high analysis throughput
• Large-Area SDD and customized X-ray tube options for exceptional sensitivity and precision for more elements and materials
• Patent-pending automatic barometric pressure correction that adjusts calibration as needed for more accurate analysis of light element
• Lightning-fast data acquisition for faster testing time
• Floating Point Processor: Provides more calculations in less time, and leverages more advnaced calibration algorithms
• Integrated Bluetooth for data input and output available in most countries
• Integrated wide area heat sinks throughout the DELTA body for high power use in extreme temperatures
• Analysis Indicator lights visible from 360° to help ensure safe use
• Advanced colortouch LCD screen for clarity, brightness, responsiveness, and energy effciency for indoor/outdoor use
• Accelerometer technology puts the unit into sleep mode to save energy when not in use; logs impacts for tool management
• USB interface port for high-speed downloads and seamless PC control
• Ergonomic rubberized handle for enhanced grip

Specifications Olympus DP-2000

Standard Accessories Olympus DP-2000

• Waterproof Carrying Case
• Two (2) Li-ion Batteries
• Electronic User Manual and User Interface Guide and Printed Quick Start Guide
• Docking Station
• Mini USB Cable
• 316 Stainless Steel Calibration Check Reference Coin
• Ten (10) Spare Windows
• Integrated Wrist Strap
• DELTA PC Software
• Factory Authorized Training & Support

Package Include :

• 1 x Olympus DP-2000 Delta Premium Alloy XRF Analyzer
• 2 x Battery Pack
• 1 x Battery Charging Station
• 1 x AC Adapter/Charger
• 1 x Power Cord
• 1 x USB Stick
• 1 x USB Cord Standard
• 1 x USB 2.0 Cord 8ft
• Prolene Window Replacements
• 1 x Hard Carrying Case
